Oil immersed transformer is a new type of high-performance transformer with a more reasonable structure and better performance. Its three-dimensional coiled iron core, due to the equilateral triangle arrangement of its three core columns, has no air gap in its magnetic circuit and is wound more tightly. The length of the three magnetic circuits is the same and the shortest, and the cross-sectional area of the core columns is closer to a circle. Therefore, the performance is further improved, the loss is reduced, the noise is reduced, the three aspects are balanced, and the third harmonic component is reduced. This product is more suitable for urban and rural, industrial and mining enterprise power grid transformation, and is more suitable for combination transformers and prefabricated substation transformers.
The S11-M-30 series is a cutting-edge, fully sealed oil-immersed distribution transformer designed for superior energy efficiency and reliable power transmission in diverse industrial and commercial applications. Engineered with advanced amorphous alloy core technology, this transformer series delivers exceptional performance while meeting stringent international energy conservation standards.
Key Features: 1.Sealed Tank Design
Features a maintenance-free, fully sealed structure that eliminates oil-air contact, preventing oxidation and moisture ingress for enhanced insulation longevity.
2. High Efficiency & Low Loss
Utilizes high-quality grain-oriented silicon steel cores and precision-wound copper windings to achieve up to 98.5% efficiency, significantly reducing no-load and load losses compared to conventional models.
3. Enhanced Safety
Integrated pressure relief device and corrosion-resistant tank ensure safe operation under extreme conditions. Meets IEC 60076 standards for short-circuit resistance and thermal stability.
4. Environmentally Optimized
Fully compliant with RoHS directives, using biodegradable insulating oil and recyclable materials for reduced environmental impact.
5. Robust Construction
Weatherproof IP55-rated enclosure with anti-vibration design enables reliable outdoor installation in harsh environments (-40°C to +40°C).
Applications:
Urban power distribution networks
Industrial parks and mining facilities
Renewable energy systems integration
Commercial complexes and infrastructure projects
Technical Advantages:
- 30-2500 kVA capacity range
- Voltage classes: 11kV/33kV (customizable)
- ≤55 dB low-noise operation
- 20% overload capacity for emergency scenarios
technical parameters:
Rated Capacity KVA
Voltage Combination
Connection Symbol
Off-load
Loss(W)
Short Circuit
Impendence(%)
Impendence(%)
High Voltage (kV)
Tapping Range(%)
Low Voltage (kV)
30
6
6.3
10
10.5
11
±5
±2x2.5
0.38
0.4
0.415
0.433
Dyn11
Yyn0
90
2.1
4
50
120
2
63
140
1.9
80
170
1.8
100
200
1.6
125
235
1.5
